PANJIT FRED series are specifically designed for EV charging system. It has low QRR with soft recovery characteristics, which can effectively reduce switching losses while suppress EMI. Its’ ultra-low leakage current would result in high robustness in harsh operating conditions.

Product Features

• Best trade-off on VF & TRR
• Soft recovery switching
• Low leakage current
• High efficiency
• Low switching loss
• High junction temperature 175℃

Recommended Devices

File type A
  • Attachment Name A
File type B
  • Attachment Name 1
ADD INQUIRY

FRED (VRRM = 600 - 1200V , IF = 4 - 60A)

Product Status
AEC-Q101
Qualified
Type
VRRM
Max.
V
IF
A
VF
Typ.
V
@IF
A
TRR
nS
IFSM
A
IR
Max.
µA
@VRRM
V
Package
Circuit
Figure
Active
-
Speedy
600
30
1.8
30
45
250
250
600
TO-247AD-2LD
Fig_254
Active
-
Speedy
600
60
1.65
60
55
400
250
600
TO-247AD-2LD
Fig_254
Active
-
Speedy
1000
30
2.65
30
95
200
250
1000
TO-247AD-2LD
Fig_254
Active
-
Speedy
1200
60
2.7
60
170
300
250
1200
TO-247AD-2LD
Fig_254
Active
-
Speedy
1200
30
3
30
135
190
250
1200
TO-247AD-2LD
Fig_254
