强茂FRED产品专为电动车充电桩的电源设计。产品于切换时具有较低的反向恢复电荷特性,并具有软恢复特性,可有效降低开关切换损耗,进而可获得较低的EMI特性。另一方面此产品亦具备超低漏电特性,适合应用于高温的应用环境。

Product Features

• Best trade-off on VF & TRR
• Soft recovery switching
• Low leakage current
• High efficiency
• Low switching loss
• High junction temperature 175℃

推荐料号

File type A
  • Attachment Name A
File type B
  • Attachment Name 1
ADD INQUIRY

FRED (VRRM = 600 - 1200V , IF = 4 - 60A)

Product Status
AEC-Q101
Qualified
Type
VRRM
Max.
V
IF
A
VF
Typ.
V
@IF
A
TRR
nS
IFSM
A
IR
Max.
µA
@VRRM
V
Package
Circuit
Figure
Active
-
Speedy
600
30
1.8
30
45
250
250
600
TO-247AD-2LD
Fig_254
Active
-
Speedy
600
60
1.65
60
55
400
250
600
TO-247AD-2LD
Fig_254
Active
-
Speedy
1000
30
2.65
30
95
200
250
1000
TO-247AD-2LD
Fig_254
Active
-
Speedy
1200
60
2.7
60
170
300
250
1200
TO-247AD-2LD
Fig_254
Active
-
Speedy
1200
30
3
30
135
190
250
1200
TO-247AD-2LD
Fig_254
